The Mr Circuit Digital Electronics with Integrated Circuits Deluxe Lab #1501-LAB with Manual - We call it "Digital Magic"
Teachers love this lab because Mr Circuit Labs are reusable, you can offer real electronics technology training for a very few dollars per student.
Are you looking for an engaging way to teach or learn basic Digital Electronics concepts to STEM and future Robotics Engineers and Technicians? We call it "Digital Magic".
Give your students the skill-set they need to become electronic technicians and equipment designers. Teacher ease and flexibility were a foremost consideration in creating this lab.
Why Choose the Mr. Circuit Digital Magic Lab?
- Hands-on Learning: Build real working circuits using a solderless circuit board and included components.
- Comprehensive Curriculum: This lab includes 5 theory lessons and 30 experiments that cover digital logic gates, integrated circuits, timers, counters, and more.
- Step-by-Step Instructions: The lab manual guides you through each experiment with easy-to-follow pictorial and schematic diagrams.
- Versatile Application: Ideal for STEM education, robotics, drones, automotive, ham radio, and more.
- Teacher-Friendly: No electronics background needed! Online quizzes and answer keys are available for assessment, and free tech support is included.
What You'll Learn:
- Digital vs. Analog Electronics
- Logic Gates (AND, OR, NOT, NAND, NOR)
- Integrated Circuits (ICs)
- Timers, Counters, Dividers, Multiplexers, Demultiplexers
- And much more!
Included in this Lab:
- Mr. Circuit Digital Magic Lab Manual
- All electronic components required for the 35 lessons & experiments
- Solderless Circuit Board
Components Include:
- Resistors
- Capacitors (disc and electrolytic)
- Integrated Circuits (ICs): 4011, 4029, 4051, 4511, 555
- Transistor NPN 3904
- LEDs
- Seven-Segment LED Display
- Power Diodes
- Pushbutton Switch
- Potentiometer
- Photocell
- Jumper Wires
- 9-Volt Battery Snap
- Solderless Circuit Board (830 holes)
Keywords: Mr. Circuit, Digital Magic Lab, Electronics Education, STEM, Robotics, Drones, Experiments, Logic Gates, Integrated Circuits, Hands-on Learning, Teacher Resources
When you order this Mr Circuit Lab, #1501-LAB, you will receive a white lab box with all the experiment parts, a link to the online quizzes for your students, and a PRINTED LAB MANUAL. If you use a Learning Management System, like Blackboard or Schoology, we can help your put the our quizzes into it.
- For the teacher, it is not necessary to have a background in digital electronics to offer this lab to their students.
- Tech Support for instructors is available by email or phone. 805-295-1642 MrCircuit23@gmail.com
- There are written quizzes along with answer keys for the teacher to use to evaluate the progress of their students.
We accept Credit / Debit Cards or Public School Purchase Orders.
Thank you from Gary Gibson, author and educator
Mr Circuit Technology 805-295-1642 Gary@MrCircuitTechnology.com
We ship orders the same business day we receive them.
Table of Contents for the Mr Circuit Digital Magic Lab
Introduction, Educational Objectives, and Prerequisites, Recommendations... Page 01
Parts Inventory Sheet.……………………………………………………… Page 02
Troubleshooting Guide ………………………………….…………………. Page 03
Lesson 1: Introduction to Digital Electronics……..……..4
Lesson 2: Logic Circuits…………………………..….….5
Lesson 3: Using the Solderless Circuit Board……...…....6
Exp 1: A Logic Indicator…………………………………8
Exp 2: The AND Logic Gate…………………………….10
Exp 3: The OR Logic Gate………………………………12
Exp 4: The NOT (Inverter) and YES Circuits…….….…. 14
Exp 5: The NOR Logic Gate……………………….…….16
Lesson 4: Integrated Circuits…………………………….18
Exp 6: The NAND Logic Gate…………………..……….20
Exp 7: A Two-Gate Clock……………………………...…22
Exp 8: A Two-Gate Timer………………………..….……24
Exp 9: A Basic Memory Circuits…………………….…...26
Exp 10: The 555 Timer………………………………....…28
Lesson 5: Numbering Systems and Binary Numbers…….30
Exp 11: The Binary Counter………………..…………….32
Exp 12: The Decade Counter……………….……………..34
Exp 30: A Digital Die (dice).……………………..…….....70
Exp 13: Dividers…………………………………………..36
Exp 14: The Seven-Segment Display……………..………38
Exp 15: The Seven-segment Decoder………………..…....40
Exp 16: A Digital Counter with Display…………….…....42
Exp 17: An Up/Down Counter with Display……………..44
Exp 18: The Multiplexer/Demultiplexer……………..…...46
Exp 19: Variable Speed Chasing Lights……………….....48
Exp 20: A Logic Probe………………………..……..……50
Exp 21: A One-Shot Touch Generator………………..…...52
Exp 22: A Pulse Train Generator……...……………..……54
Exp 23: A Digital Heads or Tail Game……………....……56
Exp 24: A Double Decision Maker………………..……...58
Exp 25: A Stop-Action Reaction Tester…………….…….60
Exp 26: An ON/OFF Touch Switch…….…………….…..62
Exp 27: A Digital Stepping Touch Switch……………..…64
Exp 28: A Photo-Electric Motion Sensor Circuit……...….66
Exp 29: A Random Number Generator………………..….68
